Microfocus closed tube X-ray source parameters :

• Input power
  +24 VDC
• X-ray tube voltage(kV)
  90/120/130/150
• Focal size(μm)
  min5
• Minimum distance focus/target(FoD)(mm)
  7

Flat panel detector parameter :

• Model
  IGZO
• scintillator
  CS1/DRZ-STD
• Pixel size(um)
  76/85/100
• Pixel matrix
  1536×1536
• Effective imaging area(mm²)
  130×130/300×243
• Spatial resolution(lp/mm)
  6.6/5.8/5
